GLOVEBOX (KK-PURI) – KIYON

Glovebox is designed to provide a hermetically
sealed & highly customized working space
under a very tightly controlled.

KK-PURI

Glovebox is designed to provide a hermetically
sealed & highly customized working space
under a very tightly controlled.







Specification

Purifier System
  • Automatic atmosphere reduction control for less than 1 ppm atmosphere
  • Oxygen/Moisture removal to less than 1 ppm, Control : PLC type
    (Heat, Vacuum, Purge, Refill : 13 hours)
  • Pneumatic valve for Regeneration, Circulation Blower : 63 CFM (Variable Speed Control)
  • Purifier: 1 set (Single Column Purifier), Purifier Charger Capacity
    (Molecular sieve & Copper Oxide)
  • Automatic Pressure Controller (7″ Full Color Touch Panel)
  • Pressure Range: -12.5 to 12.5 mbar, Limits easily adjustable.
  • Manual foot switch operate.
  • Two solenoid valves are operated.
  • 1 set of Vacuum Pump : 180L/min. Intake Type: NW25. Ultimate pressure : 5 x 10-4 torr
  • Two Stage, Power 220V, 1 Phase
