MODEL: MICRO XRF A SERIES
SPECIFICATION
| Element Range: | Aluminium 13 to Uranium 92 |
| X-ray excitation: | 50 W Mo target Capillary Optics @7.5µm FWHM at 17 KeV
Optional: Cr or W |
| Detector: | Large window Silicon drifted detector with 190eV resolution or better |
| Number of analysis layers and elements: | 5 layers (4 layers + base) and 10 elements in each layer. Composition analysis of up to 30 elements simultaneously |
| Filters/Collimators: | 4 primary filters |
| Output Focal Depth: | Fixed at 0.08″ (2.03mm) |
| Digital Pulse Processing: | 4096 CH digital multi-channel analyzer with flexible shaping time. Automatic signal processing, including dead time correction and escape peak correction |
| Computer: | Intel CORE i5 9th gen. desktop processor, solid state hard drive, 16GB RAM, Microsoft Windows 11 Professional 64bit equivalent |
| Camera optics: | 1/4″ CMOS-1280×720 VGA resolution |
| Video Magnification: | 140X Micro & 7X Digital Zoom: 9X Macro & Table View |
| Power Supply: | 720W, 100~240 volts; frequency range 47Hz to 63Hz |
| Weight: | 1000kg (2200 lbs) |
| Working Environment: | 68°F (20°C) to 77°F (25°C) and up to 98% RH, non-condensing |
| Programmable XYZ: | XYZ travel: 600mm (23.6″) x 600mm (23.6″) x 89mm (3.5″)
XY tabletop: 559mm (22″) x 584mm (23″) XYZ-axis precision: 1um (40u”) |
| Internal Dimensions: | Height: 102mm (4″), Width: 1397mm (55″), Depth: 1473mm (58″) |
| External Dimensions: | Height: 1778mm (70″), Width: 1473mm (58″), Depth: 1575mm (62″) |
| Other New Features: | Z protection array, Auto focus, Focus laser, Pattern recognition, Semi S2 S8 compliant-ready |
