STEALTH BIG BAG KING METAL DETECTOR – FORTRESS

Origin: CANADA

Brand:

Category:

The Stealth Big Bag Metal Detector is a custom-manufactured solution designed for inspecting large bags in various industries. It features high sensitivity levels and digital signal processing technology to detect the smallest ferrous, non-ferrous, and stainless steel contaminants. The built-in data collection software ensures compliance with strict HACCP regulations.

STEALTH BIG BAG KING METAL DETECTOR – FORTRESS

KEY FEATURES:

  • High Sensitivity Detection:
    • Detects 2.0mm Stainless Steel (316) in 50-100 lb (25-50 kg) bags.
    • Also detects 1.5mm Ferrous and 2.0mm Non-Ferrous metals.
  • Advanced Digital Signal Processing (DSP):
    • Ensures ultra-sensitive detection.
    • Provides automatic calibration and self-diagnostic testing.
  • Data Collection & Compliance:
    • Includes Contact Reporter Lite Software for detailed data collection.
    • USB port for easy access to QA reports, configuration, and firmware updates.
  • Rugged & Reliable Build:
    • BSH extra-rugged casing for harsh environments.
    • Epoxy resin liner for heavy wash-down applications or dry liner for wipe-down applications.
  • User-Friendly & Secure:
    • Multi-level password protection for security.
    • Multi-language control panel interface.
    • Modular design for fewer components and easier upgrades.

APPLICATIONS:

This metal detector is widely used in:

  • Food Industry: Flour, powders, grain, spices, food additives.
  • Pharmaceutical & Nutraceutical Industry.
  • Bulk Products & Confectionery.



AVAILABLE OPTIONS & CUSTOMIZATION:

  • Custom Aperture Sizes for different large bag dimensions.
  • Heavy-duty integrated conveyor systems.
  • Remote mounting available (up to 4000ft / 1,200m).
  • Network Communications: RS485, Ethernet, Wireless.



TECHNICAL SPECIFICATIONS:

Construction Aluminum Epoxy Painted or Stainless Steel
Protection Rating NEMA 4/IP65K (Aluminum) or NEMA 4X/IP69K (Stainless Steel)
Power Supply 90-250V, Single Phase, 1 Amp, 50-60Hz
Display Panel Can be mounted remotely
